Betonmixer Cifa HD SeriesK40H
Series
HD Series
Engine
presa di forza
Power Needed
kW
Drum Geometric Volume
12.02-23.75 m³
Filling Coefficient
56-63 %
Rotation Speed
14 rpm
Pipeline Diameter
2200-2400 mm
Rollers
1+1 - 2+2
Water Pump Output
560 l/min
Water Pump Pressure
4 bar
Water Meter Scale
0 ÷ 500
Water Tank Capacity
800-1200
Frame Length
5000-7060 mm
Center of Gravity
2019-2940 mm
Maximum Height
2650-2800 mm
Maximum Width
2355-2500 mm
Total Net Weight
4043-5910
Betonmixer Cifa HD Series
Pumping unit
Management system
